DMTonline offers a full range of 4.3-10 connectors and adapters, which are engineered for the wireless market and are ideal for applications requiring low passive intermodulation, or PIM.
4.3-10 connectors offer the same, robust design as 7/16 connectors but are smaller and up to 40% lighter, allowing for much more dense, lighter weight applications. These designs are IP-67 compliant to protect against dust and water ingress for outdoor applications, and provide excellent VSWR performance up to 6.0 GHz. Separate electrical and mechanical components yield very stable PIM performance regardless of coupling torque, allowing for easier installation. Silver plated contacts and White Bronze plated bodies offer a high-degree of conductivity, corrosion resistance, and durability.
Features and Benefits
- 100% PIM tested
- 50 Ohm nominal impedance
- Ideal for applications requiring low PIM and low attenuation
- IP-67 compliant
Applications
- Distributed Antenna Systems (DAS)
- Base Stations
- Wireless Infrastructure
| Electrical | |
| Impedance | 50 %3F |
| Frequency | DC to 6 GHz |
| VSWR | |
| DC to 4 GHz | 0.015 max. (RL %3F 36 dB) |
| 4 to 6 GHz | 0.025 max. (RL %3F 32 dB) |
| Center and outer contact resistance | %3F 1.0 m%3F |
| Insulation resistance 9.2.5. initial %3F 5 G%3F | %3F 5 G%3F |
| Proof voltage at sea level | 2500 V |
| PIM | |
| 2 × 20 W | %3F166 dBc (0.4 to 4 GHz) |
| 2 × 40 W | %3F160 dBc (0.4 to 4 GHz) |
| Environmental | |
| Temperature range | %3F55 to +90 °C |
| Mechanical | |
| Mating cycles | >100 |
| Center contact captivation (axial force) | 30 N |
| Coupling torque | %3F 5 Nm |
| Engagement force | typ. 100 N |
| Separation force | typ. 80 N |
| Coupling mechanism retention force | %3F 450 N |
| Vibration | 100 m/s2, 10 g acceleration, 2 %3F 200 Hz |
| Shock | 981 m/s2, 100 g acceleration, ½ sin 6 ms |
These characteristics are typical and may not apply to all connectors. Coax stik
